UL2464 shielded cable
Product application
This product has ULcUL authentication can be used for the North American market, the series of cable overall soft, workmanship and tight, especially for in industrial automation, mechanical and electrical equipment, machine tools, and other machinery and equipment, logistics transmission system, production line control system in electrical connection, suitable for industrial environment, dry or wet indoor and outdoor fixed installation, tinned copper braided shielding the cable has strong anti external electromagnetic interference ability, guarantee the transmission of data and signal stability.
Product structure
Conductor: what a fine twisted into a bundle of bare copper wire, accord with UL758 standard
Insulation: PVC or semi-rigid PVC insulation
Core wire: wire stranding
Black core white with yellow wire digital code.
The color of the core line, with yellow wire
Black core of white yellow wire without a digital code.
The color of the core line, yellow wire without
Shielding: tin plated copper braid
Outer sheath: PVC soft material
Jacket color: Black
Product characteristic
Working voltage: 300V
Test voltage: 2000V
Insulation resistance: 20M ohm /KM (20 C)
Fixed installation: about 6 * D (cable outside diameter)
Working temperature:
Fixed installation: -15 to +80
Flame retardant: accord with FT1, VVV-1
