PUR Flexible signal cable
Product application:
This product is specially used for industrial automation, electromechanical equipment, machine tools, and other machinery and equipment, logistics transmission system and production line control system in electrical connection, especially suitable for for industrial environment in continuous reciprocating movement installation. The inner sheath makes the cable more round and compact. Pur sheath enable the cable suitable for extremely harsh industrial environment and corrosive coolants and lubricants occasions, has excellent oil resistance, anti wear performance, anti microbial, anti hydrolysis, chemical corrosion resistance, anti ultraviolet, cable protection is not affected by mechanical stress damage. Can be used for E-Chains, suitable for frequent high-speed continuous bending. Tin plated copper wire shield enables the cable to have strong anti electromagnetic interference ability, and ensure the stability of the cable system.
product mix
Conductor: what a fine twisted into a bundle of bare copper wire
Insulation: specially made PVC hybrid material or high strength TPE material
Core wire: wire stranding
Core identification: black core of white digital encoding, with yellow wire
The color of the core line, with yellow wire
Black core of white digital encoding, yellow wire without
The color of the core line, yellow wire without
Inner sheath: high elastic PVC mixture / high strength TPE mixture
Shield: tin plated copper braid shield (MIN80% shield rate)
Outer sheath: special PUR hybrid material (highly resistant to oil)
Outer sheath color: Black (or other)
Product characteristics
Working voltage: 300V
Test voltage: 2000V
Insulation resistance: 20M ohm /KM (20 C)
Minimum bending radius: mobile installation: about 7.5 x D (external diameter of cable)
The number is not less than 8 million times bending simulation
Maximum moving speed: overhead speed: 3M/S
Sliding speed: 2M/S
Plus speed: 20M/S2
Fixed installation: about 5 x D (external diameter of cable)
Operating temperature / mobile installation: -20 to +80
Operating temperature / fixed installation: -30 to +80
